Air Compressor, Twin Motor, Onboard ARB Air Compressor, 12V, CKMTA12

Air Compressor, Twin Motor, Onboard ARB Air Compressor, 12V, CKMTA12

ARB 4x4

SKU:CKMTA12

Regular price $639.95 USD
Regular price Sale price $639.95 USD
Sale Sold out
Shipping calculated at checkout.
ARB’s new CKMTA12 and CKMTA24 twin on-board compressor kits are specifically designed to meet the demand for a compact yet high-volume compressed air source. These compressors are ideal for powering most air tools and meeting the actuation and control needs of the ARB Air Locker. Built to withstand the harsh and demanding conditions faced by ARB Air Locker users, these compressors offer reliable performance in a durable, space-efficient package.

Features & Benefits

  • Designed for inflating Tires and Air Locker activation when used in conjunction with optional accessories
  • On-board model available in either a 12V or 24V configuration
  • Suitable for many air tools when used in conjunction with a 4L air tank (optional with on-board models)
  • 100% duty cycle
  • Sealed for moisture and dust resistance
  • Hard anodized cylinder bores for reduced friction
  • Teflon impregnated carbon fiber piston seals for maximum trouble free life
  • Anodized mounting bracket dissipates heat
  • Integrated pressure switch, relays and IP55 (waterproof/dustproof) brushless fan cools electronics, motors and cylinder heads
  • Over-pressure safety valve equipped

Specifications

  • Prop 65No
  • Volts12V
  • Width7.5 inch
  • Height4 inch
  • Length10.8 inch
  • Weight17.4 lb
  • Max Psi150
  • Max Amps68.6
  • IP RatingIP55
  • Duty Cycle100% 60/0
  • Air Flow 0PSI6.16CFM
  • Air Flow 29PSI4.68CFM
  • Design: Onboard
  • Warranty3 YR
