Dana 60, Dodge, Ford, GM, King Pin, Wheel Bearing and Seal Kit

This is a wheel bearing and seal kit for any kingpin D60 (Dodge, Ford and GM all take the same front wheel bearings and seals.  Check the specifications below to get the dimensional break down.  There's also an exploded view in the images, see #74, 76, 77.

This wheel bearing kit has enough parts to do one axle (both sides).  All of our bearing kits come with Timken bearings, and we sell it as a complete axle kit to keep the pricing low.  If you only need to do one side, buy this kit and save the extra parts.  At these prices we need to keep it complete.  If you're hard pressed on cash, and need to buy only one side, give us a call and we'll piece it together for you.  It's going cost more than half a kit, but less than the whole kit.  The kit comes with inner and outer bearings, the associated races, and the hub seal.  You supply the grease ; )

Specifications:

• Inner bearing ID - 2.2500"
• Inner cup OD - 3.8125"
• Outer bearing ID - 2.000"
• Outer cup OD - 3.2500"
• Seal OD - 3.876" (for bore of 3.876)
• Seal ID - 2.750" (this is the OD of the spindle surface)
